Electric distributor for positioning signals
FXV 33** EasySwitch
How energy efficiency is improved
Distributor for intelligent, energy-efficient control with variable channel assignment
Jellemzők
-
For the control of a maximum of twelve thermal actuators for unit valves and the connection of up to eight room thermostats
-
Flexible assignment of the actuators to the room thermostats via rotary switch
-
Distribution of the power supply, the positioning signals and a shared time programme for room operating units
-
Easy to change channel assignment without rewiring
-
Pump logic module for activating a circulation pump
-
Input for timer for individual forwarding of time commands to the heating zones
-
LED status indicators for power supply, pump logic module and active heating channels
-
Integrated cable guides and terminal connection without tools
-
Fitting on DIN rail or wall mounting
Adatlapokat
Szerelési útmutató
FXV 33**: Electric distributor for
pdf : 909 KB
pdf
FXV 3308
pdf : 2 MB
pdf
